soulution 312 stereo amplifier
Retail: $28,975
More power reserves make the 312 stereo amplifier sound even more dynamic than its predecessor.
Highlights
New power supply
Four new cutting-edge switched-mode power supplies modules deliver 1,200 VA of continuous power for the power amplfier section with a peak power capability of up to 4’200 VA for more than 5 seconds. They feature high performance filtering at the input and output, and high speed soulution voltage regulators to deliver considerably more stable power than any conventional, transformer-based technology.
Power amplifier
The amplification circuit of the 312 is based on the technology used in our Series 5 amplifiers. Current amplification is done in three stages, each with a narrow, almost linear operating range.
Operation
The 312 stereo amplifier is operated via its front panel button. Multiple configuration functions allow optimisation of the entire audio system.
If you are interested in the 312 please contact us HERE
Retail: $28,975
More power reserves make the 312 stereo amplifier sound even more dynamic than its predecessor.
Highlights
New power supply
Four new cutting-edge switched-mode power supplies modules deliver 1,200 VA of continuous power for the power amplfier section with a peak power capability of up to 4’200 VA for more than 5 seconds. They feature high performance filtering at the input and output, and high speed soulution voltage regulators to deliver considerably more stable power than any conventional, transformer-based technology.
Power amplifier
The amplification circuit of the 312 is based on the technology used in our Series 5 amplifiers. Current amplification is done in three stages, each with a narrow, almost linear operating range.
Operation
The 312 stereo amplifier is operated via its front panel button. Multiple configuration functions allow optimisation of the entire audio system.
If you are interested in the 312 please contact us HERE
Retail: $28,975
More power reserves make the 312 stereo amplifier sound even more dynamic than its predecessor.
Highlights
New power supply
Four new cutting-edge switched-mode power supplies modules deliver 1,200 VA of continuous power for the power amplfier section with a peak power capability of up to 4’200 VA for more than 5 seconds. They feature high performance filtering at the input and output, and high speed soulution voltage regulators to deliver considerably more stable power than any conventional, transformer-based technology.
Power amplifier
The amplification circuit of the 312 is based on the technology used in our Series 5 amplifiers. Current amplification is done in three stages, each with a narrow, almost linear operating range.
Operation
The 312 stereo amplifier is operated via its front panel button. Multiple configuration functions allow optimisation of the entire audio system.
If you are interested in the 312 please contact us HERE
Specifications
Mains 100– 240 V (50 – 60 Hz)
Power consumption < 0.5 W Standby. idle 110W
Analog inputs 1 × balanced (XLR)
Input impedance 2 kΩ balanced (XLR)
LINK (remote turn-on) 2 x phone jack (3.5mm)
Loudspeaker 2 pair loudspeaker binding posts
Gain + 26 dB
Power output
100 W @ 8 Ω
200 W @ 4 Ω
400 W @ 2 Ω (< 5 sec.)
Output current max 30 A
Frequency response (– 3 dB) 0 – 800 kHz
Phase shift @ 20kHz < - 3°
THD < 0.0004%
Spot noise (input related) < -140 dBV/√Hz
Damping factor > 5000
Dimensions (WxDxH) 430 x 490 x 142 mm
Weight ~17 kg
