Audio-Technica AT-BHA100
The AT-BHA100 balanced headphone amplifier is designed to deliver unmatched audio quality from high-resolution sound sources, and is ideal for use with hi-fi headphones such as the ATH-ADX5000, ATH-MSR7b, and those in the ATH-AW Series. This compact desktop unit is compatible with Direct Stream Digital (DSD) and other high-definition formats to reproduce every detail of the original recording.
The AT-BHA100 balanced headphone amplifier is designed to deliver unmatched audio quality from high-resolution sound sources, and is ideal for use with hi-fi headphones such as the ATH-ADX5000, ATH-MSR7b, and those in the ATH-AW Series. This compact desktop unit is compatible with Direct Stream Digital (DSD) and other high-definition formats to reproduce every detail of the original recording.
The AT-BHA100 balanced headphone amplifier is designed to deliver unmatched audio quality from high-resolution sound sources, and is ideal for use with hi-fi headphones such as the ATH-ADX5000, ATH-MSR7b, and those in the ATH-AW Series. This compact desktop unit is compatible with Direct Stream Digital (DSD) and other high-definition formats to reproduce every detail of the original recording.
Specifications
Headphone Amplifier
Corresponding Headphone Impedance: 16 – 600 ohms
Instantaneous Maximum Output Level: 6.3 mm headphone output (10%, 1 kHz): 680 mW + 680 mW (16 ohms load) 320 mW + 320 mW (32 ohms load) 240 mW + 240 mW (64 ohms load) 30 mW + 30 mW (600 ohms load) Balanced output (10%, 1 kHz): 1,500 mW + 1,500 mW (16 ohms load) 1,200 mW + 1,200 mW (32 ohms load) 800 mW + 800 mW (64 ohms load) 120 mW + 120 mW (600 ohms load)
Frequency Response: Line input: 10 Hz – 100 kHz (0, -3 dB at 32 ohms 10 mW output); Balanced input: 10 Hz – 100 kHz (+0.5, -3 dB at 32 ohms 10 mW output)
Total Harmonic Distortion: <=0.25% (20 Hz - 20 kHz at 32 ohms and 1 mW output)
Gain: 6.3 mm headphone output: 10 dB (high gain), 1.5 dB (low gain) Balanced output: 16 dB (high gain), 7 dB (low gain)
